Eminence DELTA-12LFC 4 Ohm
| Anzahl | Stückpreis |
|---|---|
| Bis 2 |
156,00 €*
|
| Bis 4 |
154,50 €*
|
| Bis 6 |
153,00 €*
|
| Ab 7 |
151,50 €*
|
Versandfertig in 1 Tag, Lieferzeit 2-5 Arbeitstage
Produktnummer:
SW11807
Produktinformationen "Eminence DELTA-12LFC 4 Ohm"
Beschreibung Eminence DELTA-12LFC 4 Ohm
DELTA-12LFC - Tieftöner für Pro-Audio- Bass/Mitten Anwendungen oder Stage Monitore in einem geschlossenen Gehäuse. Auch als Tieftöner für Bassgitarre oder PA im Bassreflex- Gehäuse geeignet.
| SPECIFICATION DELTA-12LFC | |
| Nominal Basket Diameter | 12", 305 mm |
| Nominal Impedance* | 4 Ω |
| Power Rating* | |
| Program Power |
1000 W |
| Watts | 500 W |
| Resonance | 52 Hz |
| Usable Frequency Range | 45 Hz - 2.3 kHz |
| Sensitivity* | 93.1 dB |
| Magnet Weight | 56 oz. |
| Gap Height | 0.375", 9.5 mm |
| Voice Coil Diameter | 2.5", 64 mm |
THIELE & SMALL PARAMETERS DELTA-12LFC |
|
| Resonant Frequency (fs) | 52 Hz |
| DC Resistance (Re) | 3.2 Ω |
| Coil Inductance (Le) | 0.94m H |
| Mechanical Q (Qms) | 8.21 |
| Electromagnetic Q (Qes) | 0.47 |
| Total Q (Qts) | 0.44 |
| Compliance Equivalent Volume (Vas) | 63.7 liters / 2.25 cu.ft. |
| Peak Diaphragm Displacement Volume (Vd) | 243 cc |
| Mechanical Compliance of Suspension (Cms) | 0.17 mm/N |
| BL Product (BL) | 10.9 T-M |
| Diaphragm Mass Inc. Airload (MMs) | 53 grams |
| Efficiency Bandwidth Product (EBP) | 111 |
| Maximum Linear Excursion (Xmax) | 4.8 mm |
| Surface Area of Cone (Sd) | 506.7 cm2 |
| Maximum Mechanical Limit (Xlim) | 13.5 mm |
| MOUNTING INFORMATION DELTA-12LFC | |
| Recommended Enclosure Volume | |
| Sealed | 21-74 liters / 0.7-2.6 cu.ft. |
| Vented | 28-110 liters / 1-3.9 cu.ft. |
| Driver Volume Displaced | 0.079 cu.ft. / 2.25 liters |
| Overall Diameter | 12.03", 305.6 mm |
| Baffle Hole Diameter | 11.07", 281.2 mm |
| Front Sealing Gasket | Yes |
| Rear Sealing Gasket | Yes |
| Mounting Holes Diameter | 0.25", 6.4mm |
| Mounting Holes B.C.D. | 11.59", 294.4mm |
| Depth | 5.35", 135.9 mm |
| Net Weight | 11.8 lbs, 5.35 kg |
| Shipping Weight | 14 lbs, 6.35 kgs |
| MATERIALS OF CONSTRUCTION DELTA-12LFC | |
| Coil Construction | Copper voice coil |
| Coil Former | Kapton former |
| Magnet Composition | Ferrite magnet |
| Core Details | Vented and extended core |
| Basket Materials | Pressed steel basket |
| Cone Composition | Treated paper cone |
| Cone Edge Composition | Cloth cone edge |
| Dust Cap Composition | Solid composition paper dust cap |
Eminence DELTA-12LFC
| Coaxial: | NEIN |
|---|---|
| Größe: | 12" |
| Impedanz: | 4 Ohm |
| Magnet: | Ferrit |
| Qts: | 0,41 - 0,50 |
| Sperrgut: | NEIN |
| X-MAX: | 0,1 - 5,0 mm |
