Eminence Kappa Pro-15LF 8 Ohm 15 Zoll Tieftöner
| Anzahl | Stückpreis |
|---|---|
| Bis 2 |
232,00 €*
|
| Bis 4 |
230,00 €*
|
| Bis 6 |
228,00 €*
|
| Ab 7 |
226,00 €*
|
Versandfertig in 1 Tag, Lieferzeit 2-5 Arbeitstage
Produktnummer:
SW12769
Produktinformationen "Eminence Kappa Pro-15LF 8 Ohm 15 Zoll Tieftöner"
Beschreibung Kappa Pro-15LF 8 Ohm 15"
Der Eminence Kappa Pro-15LF ist ein leistungsstarker 15 Zoll Tieftöner, der für professionelle Audioanwendungen entwickelt wurde. Er ist besonders gut geeignet für Subwoofer und Bassreflexgehäuse und liefert tiefe, kraftvolle Bässe mit hoher Belastbarkeit. Durch seine robuste Konstruktion und die hervorragende Klangqualität ist dieser Lautsprecher ideal für Konzert- und PA Systeme, Festinstallationen und mobile Sound-Anlagen.
Technische Daten Kappa PRO-15LF
| Nominal Basket Diameter | 15", 381 mm |
| Nominal Impedance* | 8 Ω |
| Power Rating* | |
| Program Power |
1200 W |
| Watts | 600 W |
| Resonance | 35 Hz |
| Usable Frequency Range | 38 Hz - 1.8 kHz |
| Sensitivity* | 97.8 dB |
| Magnet Weight | 120 oz. |
| Gap Height | 0.375", 9.5 mm |
| Voice Coil Diameter | 3", 76 mm |
| THIELE & SMALL PARAMETERS Kappa Pro-15LF | |
| Resonant Frequency (fs) | 35 Hz |
| DC Resistance (Re) | 6.5 Ω |
| Coil Inductance (Le) | 1.4m H |
| Mechanical Q (Qms) | 7.3 |
| Electromagnetic Q (Qes) | 0.32 |
| Total Q (Qts) | 0.3 |
| Compliance Equivalent Volume (Vas) | 198.8 liters / 7.02 cu.ft. |
| Peak Diaphragm Displacement Volume (Vd) | 571.2 cc |
| Mechanical Compliance of Suspension (Cms) | 0.2 mm/N |
| BL Product (BL) | 21.6 T-M |
| Diaphragm Mass Inc. Airload (MMs) | 102 grams |
| Efficiency Bandwidth Product (EBP) | 112 |
| Maximum Linear Excursion (Xmax) | 6.7 mm |
| Surface Area of Cone (Sd) | 856.3 cm2 |
| Maximum Mechanical Limit (Xlim) | 18 mm |
| MOUNTING INFORMATION Kappa Pro-15LF | |
| Recommended Enclosure Volume | |
| Sealed | N/a |
| Vented | 76.5-164 liters / 2.7-5.8 cu.ft. |
| Driver Volume Displaced | 0.152 cu.ft. / 4.31 liters |
| Overall Diameter | 15.21", 386.3 mm |
| Baffle Hole Diameter | 14", 355.6 mm |
| Front Sealing Gasket | Yes |
| Rear Sealing Gasket | Yes |
| Mounting Holes Diameter | 0.28", 7.1mm |
| Mounting Holes B.C.D. | 14.56", 369.8mm |
| Depth | 6.57", 166.9 mm |
| Net Weight | 22.3 lbs, 10.12 kg |
| Shipping Weight | 24.8 lbs, 11.25 kgs |
| MATERIALS OF CONSTRUCTION Kappa Pro-15LF | |
| Coil Construction | Copper voice coil |
| Coil Former | Polyimide former |
| Magnet Composition | Ferrite magnet |
| Core Details | Vented and extended core |
| Basket Materials | Die-cast aluminum basket |
| Cone Composition | Paper cone |
| Cone Edge Composition | Cloth cone edge |
| Dust Cap Composition | Solid composition paper dust cap |
Eminence Kappa PRO-15LF
| Coaxial: | NEIN |
|---|---|
| Größe: | 15" |
| Impedanz: | 8 Ohm |
| Magnet: | Ferrit |
| Qts: | 0,26 - 0,30 |
| Sperrgut: | NEIN |
| X-MAX: | 5,1 - 10,0 mm |
