93 db 1W / 1m average sensitivity
51 mm high temperature voice coil
400 W AES program power
Ferrite 134 mm magnet structure
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
10"/262 inch/mm8 Ohm 6.05 Ohm200 W400 W(100-1000 Hz) 93 dB/W/m60 - 3000 Hz51 mmCopper Glass fiber17 mm7 mmGlass Fiber Die cast aluminiumFerrite1.35 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
48.06 Hz7.8620.3650.34931.94 Litres49.25 grams5.3 Ohms317.3 cm2± 5.75 mm0.2227 mm/N14.69 T.m0.83 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
263 mm225 mm8 with dia. 7 mm244 mm113 mm3.6 kg
99 db 1W / 1m average sensitivity
51 mm high temperature aluminium voice coil
300 W AES program power
Ferrite 134 mm magnet structure
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
10"/262mm 8 Ohm5.25 Ohm150 W300 W(200-5000 Hz) 99 dB/W/m75 - 6000 Hz51 mm Aluminium Kapton™ 10 mm7 mmPaperDie cast aluminiumFerrite 1.35 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
74 Hz8.890.450.4325.9 Litres25.54 Grams5.15 Ohms317.3 cm²+/- 3.25 mm0.18 mm/N11.62 T.m0.88 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
263 mm225 mm8 with dia. 7 mm244 mm113 mm3.45 kg
97 db 1W / 1m average sensitivity
64 mm high temperature aluminium voice coil
500 W AES program power
Powerful, ferrite 169 mm magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
10"/262mm 8 Ohm5.25 Ohm150 W300 W(200-5000 Hz) 99 dB/W/m75 - 6000 Hz51 mm Aluminium Kapton™ 10 mm7 mmPaperDie cast aluminiumFerrite 1.35 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
74 Hz8.890.450.4325.9 Litres25.54 Grams5.15 Ohms317.3 cm²+/- 3.25 mm0.18 mm/N11.62 T.m0.88 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
263 mm225 mm8 with dia. 7 mm244 mm113 mm3.45 kg
100 db 1W / 1m average sensitivity
77 mm high temperature aluminium voice coil
800 W AES program power
Powerful, ferrite 180 mm magnet structure
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
10"/262 inch/mm8 Ohm 6.67 Ohm400 W800 W(200-3000 Hz) 100dB/W/m75-3500 Hz77 mmAluminiumKapton™15 mm9 mmPaperDie cast aluminiumFerrite1.33 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
59.79 Hz8.470.2550.24819.43 Litres32.30 grams5.48 Ohms317.3 cm2± 5.25 mm0.136 mm/N18.22 T.m0.60 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
263 mm225 mm8 with dia. 7 mm244 mm120 mm6.8 kg
99 db 1W / 1m average sensitivity
77 mm high temperature aluminium voice coil
800 W AES program power
Powerful, ferrite 180 mm magnet structure
Water protected cone (front)
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
10"/262 inch/mm8 Ohm6.52 Ohm400 W800 W(200-2000 Hz) 99 dB/W/m80 - 2500 Hz77 mmAluminiumKapton™15 mm9 mmKevlar PaperDie cast aluminiumFeritte1.33 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
64.70 Hz9.660.2510.24422.75 Litres38.13 grams5.43 Ohms317.3 cm2±5.25 mm0.159 mm/N18.32 T.m0.72 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
263 mm225 mm8 with dia. 7 mm244 mm120 mm6.8 kg
97 db 1W / 1m average sensitivity
77 mm high temperature aluminium voice coil
1000 W AES program power
Double aluminium demodulating rings for lower distortion and improved heat dissipation
Powerful, ferrite 180 mm magnet structure
Water protected cone (front)
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
10"/262 inch/mm8 Ohm6.05 Ohm500 W1000 W(200-2000 Hz) 97 dB/W/m65 - 3000 Hz77 mmAluminiumGlassfiber20 mm7 mmPaperDie cast aluminiumFeritte1.25 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
65,94 Hz
9.46
0.316
0.306
22,08 Litres
37,85 grams
4,81 Ohms
317.3 cm2
±8.25 mm
0.154 mm/N
15,45 T.m
0.333 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
263 mm225 mm8 with dia. 7 mm244 mm116.5 mm6.2 kg
100 db 1W / 1m average sensitivity
77 mm high temperature voice coil
800 W AES program power
Vented neodymium magnet assembly with massive heatsink
Double aluminium demodulating ring for lower distortion and improved heat dissipation
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
10"/262 inch/mm8 Ohm 7.16 Ohm400 W800 W(200-2000 Hz) 100 dB/W/m100 - 4000Hz77 mmAluminiumKapton™15 mm9 mmPaperDie cast aluminiumNeodymium1.45 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
71.36 Hz9.150.2140.20920.61 Litres34.62 grams5.58 Ohms317.3 cm2±5.25 mm0.144 mm/N20.12 T.m0.62 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
263 mm225 mm8 with dia. 7 mm244 mm148.3 mm4.75 kg
98 db 1W / 1m average sensitivity
64 mm high temperature voice coil
400 W AES program power
Vented neodymium magnet assembly
Double aluminium demodulating ring for lower distortion and improved heat dissipation
Water protected cone (front)
Very light weight
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
10"/262 inch/mm8 Ohm 6.55 Ohm200 W400 W(200-2000 Hz) 98 dB/W/m70 - 4000 Hz64 mmAluminiumKapton™12.5 mm8 mmPaperDie cast aluminiumNeodymium1.15 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
58.67 Hz 8.92 0.327 0.316 34.93 Litres 30.21 grams 5.82 Ohms 317.3 cm2 ±4.25 mm 0.244 mm/N 14.07 T.m 0.53 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
263 mm225 mm8 with dia. 7 mm244 mm107 mm2.36 kg
99 db 1W / 1m average sensitivity
77 mm high temperature aluminium voice coil
900 W AES program power
Powerful, vented 180 mm magnet structure
Double aluminium demodulating rings for lower distortion and improved heat dissipation
Silicone spider
Epoxy anti-corrosion coating of top and back plates of magnet structure
94 db 1W / 1m average sensitivity
77 mm high temperature aluminium voice coil
900 W AES program power
Powerful, vented 180 mm magnet structure
Aluminium demodulating ring for lower distortion and improved heat dissipation
Silicone spider
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
12"/310 inch/mm8 Ohm5.76 Ohm450 W900 W(50-200 Hz) 94 dB/W/m40 - 2000 Hz77 mmAluminiumGlassfiber25 mm8 mmPaper with Kevlar fibersDie cast aluminiumFerrite1.24 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
47.88 Hz7.370.3710.35458.51 Litres69.86 grams4.90 Ohms514.7 cm2± 10.5 mm0.1582 mm/N16.65 T.m0.733 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
315 mm280 mm8 eliptic 7x8 mm296 / 298 mm158 mm7.65 kg
100.5 db 1W / 1m average sensitivity
64 mm high temperature aluminium voice coil
600 W AES program power
Powerful, ferrite 169 mm magnet structure
Silicone spider
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
12"/310 inch/mm8 Ohm 6.20 Ohm300 W600 W(200-2000 Hz) 100.5 dB/W/m60 - 5000 Hz64 mmAluminiumKapton™11 mm9 mmPaper Die cast aluminiumFerrite1.35 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
53.80 Hz9.980.2610.25479.63 Litres40.65 grams5.35 Ohms514.7 cm2± 3.25 mm0.215 mm/N16.78 T.m0.69 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
311 mm280 mm8 with dia. 7 mm294 mm144.7 mm6.8 kg
98 db 1W / 1m average sensitivity
88 mm high temperature aluminium voice coil
1400 W AES program power
Powerful, vented 200 mm magnet structure
Double aluminium demodulating rings for lower distortion and improved heat dissipation
Silicone spider
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
12"/315 inch/mm8 Ohm 6.15 Ohm700 W1400 W(200-2000 Hz) 98 dB/W/m50 - 2500 Hz88 mmAluminiumKapton™19 mm11 mmPaperDie cast aluminiumFerrite1.18 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
51.43 Hz 13.58 0.272 0.267 50.07 Litres 70.76 grams 5.00 Ohms 514.7 cm2 ±6.75 mm 0.135 mm/N 20.50 T.m 0.68 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
315 mm280 mm8 eliptic 7x8 mm296 / 298 mm155 mm8.5 kg
98 db 1W / 1m average sensitivity
77 mm high temperature voice coil
900 W AES program power
Vented neodymium magnet assembly with massive heatsink
Triple aluminium demodulating rings for lower distortion and improved heat dissipation
Silicone spider
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
12"/315 inch/mm8 Ohm 6.96 Ohm450 W900 W(200 -2000 Hz) 98 dB/W/m50 - 2000 Hz77 mmAluminiumKapton™15 mm9 mmPaper with glassfiberDie Cast AluminiumNeodymium1.45 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
43.58 Hz10.390.1830.18070.45 litres59.82 grams5.00 Ohms514.7 cm2±5.25 mm0.196 mm/N20.34 T.m0.83 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
315 mm280 mm8 eliptic 7x8 mm 296 / 298 mm180.3 mm5.00 kg
95 db 1W / 1m average sensitivity
100 mm high temperature sandwich voice coil
1200 W AES program power
Vented neodymium magnet assembly with massive heatsink
Double aluminium demodulating rings for lower distortion and improved heat dissipation
Double silicone spider for improved excursion control and linearity
Water protected cone (front)
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
12"/315 inch/mm8 Ohm 7.21 Ohm600 W1200 W(100 -1000 Hz) 95 dB/W/m50 – 2000 Hz100 mmCopperGlass fiber22 mm14 mmKevlar paperDie Cast AluminiumNeodymium1.02 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
50.85 Hz6.970.20.19435.66 litres101.61 grams4.95 Ohms514.7 cm2±7.5 mm0.096 mm/N28.39 T.m1.82 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
315 mm280 mm8 eliptic 7x8 mm 296 / 298 mm185.3 mm7.8 kg
99 db 1W / 1m average sensitivity
100 mm high temperature sandwich voice coil
1200 W AES program power
Vented neodymium magnet assembly with massive heatsink
Double aluminium demodulating rings for lower distortion and improved heat dissipation
Water protected cone (front)
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
12"/315 inch/mm8 Ohm 6.04 Ohm600 W1200 W(200 -2000 Hz) 99 dB/W/m50 – 3000 Hz100 mmAluminiumGlassfiber23 mm11 mmPaper with glassfiberDie Cast AluminiumNeodymium1.30 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
50.47 Hz10.020.3150.30538.71 litres95.03 grams5.48 Ohms514.7 cm2±8.75 mm0.105 mm/N22.91 T.m0.97 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
315 mm280 mm8 eliptic 7x8 mm 296 / 298 mm180.3 mm7.8 kg
99 db 1W / 1m average sensitivity
88 mm high temperature aluminium voice coil
1200 W AES program power
Vented neodymium magnet assembly with very light weight
Two aluminium demodulating rings for lower distortion and improved heat dissipation
Silicone spider
Water protected cone ( front side)
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
12"/315 inch/mm8 Ohm 6.75 Ohm600 W 1200 W(200 -2000 Hz) 99 dB/W/m50 - 3000 Hz88 mmAluminiumGlassfiber19 mm11 mmPaper with Kevlar + glass fibersDie Cast AluminiumNeodymium1.05 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
54,42 Hz7,410.380.3654,29 Litres58,28 grams5,5 Ohms514.7 cm2±6.75 mm0.1468 mm/N17,00 T.m1,01 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
315 mm280 mm8 elliptic 7x8 mm 296 / 298 mm156 mm5.05 kg.
99 db 1W / 1m average sensitivity
100 mm high temperature sandwich voice coil
1200 W AES program power
Vented neodymium magnet assembly with massive heatsink
Double aluminium demodulating rings for lower distortion and improved heat dissipation
Silicone spider
100 db 1W / 1m average sensitivity
77 mm high temperature sandwich voice coil
900 W AES program power
Powerful, ferrite 180 mm magnet structure
Silicone spider
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
15"/388 inch/mm8 Ohm 6.32 Ohm450 W900 W(200-2000 Hz) 100 dB/W/m45 - 2500 Hz77 mmCooperGlassfiber18 mm9 mmPaper with glassfiberDie cast aluminiumFerrite1.33 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
45.08 Hz9.600.2940.286146.85 Litres81.56 grams5.32 Ohms829.6 cm2± 6.75 mm0.153 mm/N20.43 T.m1.08 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
388 mm352 mm8 eliptic 7x8 mm 370/372 mm162.5 mm7.5 kg
99 db 1W / 1m average sensitivity
77 mm high temperature sandwich voice coil
1000 W AES program power
Powerful, vented 180 mm magnet structure
Double aluminium demodulating rings for lower distortion and improved heat dissipation
Double silicone spiders for improved excursion control and linearity
Water protected cone (front)
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
15"/388 inch/mm8 Ohm 6.39 Ohm500 W1000 W(60-2000 Hz) 99 dB/W/m38 - 2500 Hz77 mmCopperGlassfiber20 mm11 mmPaperDie cast aluminiumStrontium ferrite1.20
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
38.20 Hz12.060.2740.268145.82 Litres114.40 grams5.23 Ohms829.6 cm2±7.25 mm0.152 mm/N22.91 T.m1.25 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
388 mm355 mm8 eliptic 7x8 mm 370/372 mm171.5 mm7.8 kg
100 db 1W / 1m average sensitivity
77 mm high temperature aluminium voice coil
1000 W AES program power
Powerful, vented 180 mm magnet structure
Double aluminium demodulating ring for lower distortion and improved heat dissipation
Double silicone spiders for improved excursion control and linearity
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
15"/385 inch/mm8 Ohm6.27 Ohm500 W1000 W(200-2000 Hz) 100 dB/W/m50 – 3000 Hz77 mmAluminum Kapton™21 mm11 mmPaper with glassfiberDie Cast AluminiumFerrite1.20 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
41.50 Hz12.850.3490.339161.54 Litres87.50 grams5.25 Ohms829.6 cm2± 7.75 mm0.168 mm/N18.54 T.m0.92 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
388 mm355 mm8 with dia. 7mm370/372 mm171.5 mm7.8 kg
97 db 1W / 1m average sensitivity
100 mm high temperature split sandwich voice coil
2400 W AES program power
Vented neodymium magnet assembly with massive heatsink
Triple aluminium demodulating rings for lower distortion and improved heat dissipation
Double silicon spider for improved excursion control and linearity
Water protected cone (front)
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeV. C. Diameter Voice Coil Material Voice Coil FormerVoice Coil Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
15"/388 inch/mm8 Ohm6.55 Ohm1200 W2400 W97 dB/W/m (50 -1000 Hz)38 - 1000 Hz100 mmCopperGlass fiber29 mm10 mmPaper with carbone fibersDie Cast AluminiumNeodymium1.27 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
38.49 Hz8.2550.3370.324111.94 litres146.79 grams5.3 Ohms829.6 cm2±12 mm0.117 mm/N23.62 T.m0.713 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
388 mm355 mm8 eliptic 7x8 mm 370/372 mm204.3 mm8.82 kg
97 db 1W / 1m average sensitivity
100 mm high temperature sandwich voice coil
2000 W AES program power
Powerful, vented 220 mm magnet structure
Aluminium demodulating ring for lower distortion and improved heat dissipation
Water protected cone (front)
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
15"/385 inch/mm8 Ohm 7.05 Ohm1000 W2000 W(100-200 Hz) 97 dB/W/m37 - 2000 Hz100 mmCopperGlassfiber25 mm14 mmKevlar paperDie cast aluminiumFerrite0.98 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
37.2 Hz9.20.2920.283111.02 Litres158.39 grams5.19 Ohms829.6 cm2±9 mm0.11525.64 T.m1.9 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
389 mm353 mm8 with dia. 7mm372 mm171.4 mm13.15 kg
95 db 1W / 1m average sensitivity
100 mm high temperature sandwich voice coil
2400 W AES program power
Powerful, vented 220 mm magnet structure
Double silicone spiders for improved excursion control and linearity
Double aluminium demodulating rings for lower distortion and improved heat dissipation
Water protected cone (front)
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
15"/385 inch/mm8 Ohm 6.52 Ohm1200 W2400 W(100-200 Hz) 95 dB/W/m39 - 2000 Hz100 mmCopperGlassfiber29 mm10 mmPaper with carbone fibersDie cast aluminiumFerrite1.25 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
39.81 Hz
7.84
0.321
0.308
108.5 Litres
141.53 grams
5.20 Ohms
829.6 cm2
±12 mm
0.1129
23.95 T.m
1.36 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
388 mm355 mm8 with dia. 7mm370 / 372 mm186.5 mm12.82 kg
102 db 1W / 1m average sensitivity
77 mm high temperature aluminium voice coil
800 W AES program power
Powerful, ferrite 180 mm magnet structure
Silicone spider
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
15"/388 inch/mm8 Ohm 6.39 Ohm400 W800 W(200-2000 Hz) 102 dB/W/m50 - 3500 Hz77 mmAluminiumKapton™15 mm9 mmPaper with glassfiberDie cast aluminiumFerrite1.33 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
48.78 Hz9.300.3500.337140.00 Litres73.05 grams5.6 Ohms829.6 cm2± 5.25 mm0.146 mm/N18.92 T.m0.76 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
388 mm352 mm8 eliptic 7x8 mm 370/372 mm162.5 mm7.5 kg
100 db 1W / 1m average sensitivity
100 mm high temperature sandwich aluminium voice coil
1200 W AES program power
Powerful, vented 220 mm magnet structure
Aluminium demodulating ring for lower distortion and improved heat dissipation
Double silicone spiders for improved excursion control and linearity
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
15"/385 inch/mm8 Ohm6.7 Ohm600 W1200 W(200-2000 Hz) 100 dB/W/m50 – 3000 Hz100 mmAluminum Kapton™16 mm11 mmKevlar PaperDie Cast AluminiumFerrite1.25 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
40.9 Hz10.90.2200.216150.32 Litres96.91 grams5.40Ohms829.6 cm2±5.25 mm0.156 mm/N24.70 T.m1.09 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
388 mm355 mm8 with dia. 7mm370/372 mm181 mm10.85 kg
99 db 1W / 1m average sensitivity
88 mm high temperature sandwich voice coil
1400 W AES program power
Powerful, vented 200 mm magnet structure
Double aluminium demodulating ring for lower distortion and improved heat dissipation
Water protected cone (front)
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
18"/461 inch/mm8 Ohm 5.72 Ohm700 W1400 W(50-200 Hz) 99 dB/W/m32 - 1000 Hz88 mmCooper Clad AluminiumGlassfiber24 mm12 mmpaper Die cast aluminiumFerrite1.06 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
31.76 Hz
8.05
0.337
0.324
333.62 Litres
129.55 grams
4.88 Ohms
1110 cm2
± 9 mm
0.194 mm/N
19.34 T.m
0.61 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
461 mm417 mm8 eliptic 7 x 8,5 mm438/441 mm195.5 mm10 kg
98 db 1W / 1m average sensitivity
77 mm high temperature sandwich voice coil
1000 W AES program power
Powerful, vented 180 mm magnet structure
Aluminium demodulating ring for lower distortion and improved heat dissipation
Silicone spider
Epoxy anti-corrosion coating of top and back plates of magnet structure
SPECIFICATIONS
Nominal Diameter Impedance Minimum ImpedancePower Capacity AES ¹Program Power ²Sensitivity Frequency RangeVoice Coil Diameter Voice Coil Material Voice Coil FormerV. C. Winding DepthMagnet Gap DepthCone Material Basket Magnet Flux Density
18"/461 inch/mm8 Ohm 6.40 Ohm500 W1000 W(50 - 200 Hz) 98 dB/W/m35 – 1000 Hz77 mmCopperGlassfiber20 mm11 mmPaperDie cast aluminiumFerrite1.2 T
THIELE-SMALL PARAMETERS
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
34.38 Hz8.030.3570.342241.55 Litres152.76 grams5.29 Ohms1110 cm2± 7.25 mm0.140 mm/N22.12 T.m1.49 mH
MOUNTING INFORMATION
Overall DiameterBaffle Hole Diameter Mounting HolesBolt Circle DiameterOverall DepthNet Weight
461 mm417 mm8 eliptic 7 x 8,5 mm438/441 mm192.5 mm8.55 kg
