Oberton 15HCX3572 8 Ohm
| Anzahl | Stückpreis |
|---|---|
| Bis 2 |
735,00 €*
|
| Bis 4 |
728,00 €*
|
| Bis 6 |
722,00 €*
|
| Ab 7 |
715,00 €*
|
Versandfertig in 2 Tagen, Lieferzeit 2-5 Arbeitstage
Produktinformationen "Oberton 15HCX3572 8 Ohm"
Oberton 15HCX3572
101 db SPL 1W / 1m ( LF ) average sensitivity
88 mm ( 3.5”) high temperature voice coil ( LF )
900 W AES program power ( LF )
Triple aluminium demodulating rings
Silicone spider
Water protected cone (front)
1.4” exit HF neodymium compression driver
72mm (2.85”) HF high temperature voice coil
80x60 degrees nominal dispersion
Very light weight
Oberton 15HCX3572 8 Ohm SPECIFICATIONS
|
Nominal diameter Sensitivity (200-2000 Hz) Minimum impedance HF |
388 mm (15 in)
LF 8 Ohm /HF 16 Ohm
5.97 Ohm
50 - 16000 Hz
80x60 deg
101 dB
|
THIELE-SMALL PARAMETERS 15HCX3572
|
Fs
Qms
Qes
Qts
Vas
Mms
Re
Sd
Xmax*
Cms
BL
Le at 1kHz
|
46.28 Hz
11.62
0.35
0.34
140.68 L
80.77 g
5.30 Ohms
829 cm2
± 7.25 mm
0.1464 mm/N
18.81 T.m
0.573mH
|
MOUNTING INFORMATION
| Overall diameter Depth Baffle hole diameter Bolt circle diameter Mounting holes Net weight | 388 mm (15 in)
220 mm
355 mm
370/372 mm
8 eliptic 7x8 mm
7.05 kg
|
| Coaxial: | JA |
|---|---|
| Diaphragma / Dome: | Aluminium / Cotton / Sonstige |
| Größe: | 15" |
| Impedanz: | 8 Ohm |
| Magnet: | Neodym |
| Qts: | 0,31 - 0,35 |
| Sperrgut: | NEIN |
| X-MAX: | 5,1 - 10,0 mm |
